Design Product colour: Black Illumination: No Fan diameter: 13.5 cm Number of fans: 1 fan(s)
Power Efficiency: 90% Power protection features: Short circuit, Over voltage, No load operation, Under voltage, Over power, Overcharge, Surge & inrush protection (SIP), Over total voltage Combined power (+3.3V): 100 W Power Factor Correction (PFC) type: Active Combined power (-12V): 750 W Combined power (+5V): 100 W Max output current (+3.3V): 18 A Total power: 750 W Peak power: 1650 W AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Combined power (+5Vsb): 12.5 W Combined power (+12V): 750 W
Weight & dimensions Depth: 150 mm Height: 86 mm Width: 150 mm
Performance Bearing technology: FDB 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: ATX
Packaging data Package type: Box
Ports & interfaces PCI Express power connectors (16-pin): 1 EPS power connector (8-pin): No Cabling type: Fully-Modular EPS power connector (4+4 pin): Yes PCI Express connector: Yes Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 4 Number of EPS connectors: 2 Number of SATA power connectors: 5 ATX Power connector (24-pin): Yes Motherboard power connector: 24-pin ATX
