Design Number of fans: 1 fan(s) Product colour: White Cooling type: Active On/off switch: Yes Fan diameter: 12 cm Illumination: No
Power Max output current (+5V): 20 A Combined power (+5Vsb): 12.5 W Maximum input current (@220V): 4 A Combined power (+12V): 846 W Combined power (+5V): 110 W Max output current (+12V): 70.5 A Max output current (+5Vsb): 2.5 A Combined power (-12V): 3.6 W Max output current (-12V): 0.3 A Max output current (+3.3V): 20 A Maximum input current (@110V): 8 A Power Factor Correction (PFC) type: Active Power protection features: Over power, Over current, Overheating, Short circuit, Over voltage AC input voltage: 100 - 240 V Combined power (+3.3V): 110 W Total power: 850 W Efficiency: 90% AC input frequency: 47 - 63 Hz
Performance Purpose: PC Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Gold
Packaging data Package type: Box
Ports & interfaces Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes Number of SATA power connectors: 8 CPU power connector (4+4 pin): Yes ATX power connector (20+4 pin): No Motherboard power cable length: 60 cm EPS power connector (8-pin): No ATX Power connector (24-pin): No Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 4 Cabling type: Fully-Modular
Logistics data Harmonized System (HS) code: 84733020
Safety warning Warnings: Do not open the case - risk of electric shock., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Avoid contact of the product with water or other liquids.
