Processor
Compatible processor series: AMD Ryzen 7000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Features
Motherboard form factor: ATX
Component for: PC
Product colour: Black
Audio chip: Realtek ALC4080
PC health monitoring: Fan
Motherboard chipset: AMD B650
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11 x64
Memory
Supported memory clock speeds: 6400, 5600 MHz, 4800, 5000, 6000, 6600, 6200, 5800, 5400, 5200
ECC сompatibility: Non-ECC
Maximum internal memory: 128 GB
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Weight & dimensions
Width: 304.8 mm
Depth: 243.8 mm
Network
LAN controller: Realtek RTL8125B
Bluetooth: Yes
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6E (802.11ax), 802.11a
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Bluetooth version: 5.2
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
CPU fan connector: Yes
Number of SATA III connectors: 6
Front panel connector: Yes
Chassis intrusion connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Storage controllers
RAID levels: 10, 0, 1
Supported storage drive interfaces: M.2, SATA
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
S/PDIF out port: Yes
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
HDMI version: 2.1
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Headphone outputs: 1
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 1
