Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Features
Motherboard chipset: AMD B850
Windows operating systems supported: Windows 11 x64
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Audio chip: Realtek ALC4080
Product colour: Black
Motherboard chipset family: AMD
Memory
Supported memory clock speeds: 5600, 4800, 8200 MHz
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200 MHz
ECC сompatibility: Non-ECC
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Ethernet LAN: Yes
Ethernet interface type: 5 Gigabit Ethernet
Bluetooth version: 5.4
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
USB 2.0 connectors: 4
CPU fan connector: Yes
Number of water pump connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of RGB LED pin headers: 3
Number of CPU fan connectors: 6
Total number of SATA connectors: 4
RGB LED pin header: Yes
BIOS
BIOS type: UEFI
Storage controllers
RAID levels: 1, 0, 10
RAID support: Yes
Supported storage drive interfaces: M.2, Micro SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Number of HDDs supported: 4
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
HDMI version: 2.1
Expansion slots
3rd M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 2280
3rd M.2 largest key size: 2280
2nd M.2 largest key size: 22110
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
