Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset: AMD X870
PC health monitoring: Fan, CPU, Voltage, Temperature
Motherboard chipset family: AMD
Memory
Supported memory clock speeds: 6600, 7000, 8200 MHz, 6400, 6200, 5200, 7400, 4800, 5600, 7200 MHz, 5000, 6800, 6000, 5800, 5400, 8000, 7600, 7800
ECC сompatibility: Non-ECC
Maximum internal memory: 256 GB
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory types: DDR5 DIMM
Memory slots type: DIMM
Supported memory clock speed (max): 8200+ MHz
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
LAN controller: Realtek RTL8126
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi standards: 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Internal I/O
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 10
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 6
CPU fan connector: Yes
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 2
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Number of storage drives supported: 7
Rear panel I/O ports
DisplayPorts quantity: 1
S/PDIF out port: No
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB4 Gen 2x2 ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
1st M.2 largest key size: 2280
2nd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste.
