Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
On-board graphics card: No
Features
PC health monitoring: Voltage, CPU, Fan, Temperature
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset family: AMD
Product colour: White
Motherboard chipset: AMD X870E
Memory
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8400 MHz
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Supported memory clock speeds: 8400 MHz, 4800, 6400, 5600
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Bluetooth version: 5.4
Wi-Fi standards: 802.11b, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
LAN controller: Realtek RTL8126
Internal I/O
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Number of SATA III connectors: 4
USB 2.0 connectors: 4
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Front panel connector: Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 8
RAID levels: 1, 0, 10
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Microphone in: Yes
USB4 Gen 2x2 ports quantity: 2
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
DisplayPorts quantity: 2
S/PDIF out port: Yes
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
4th M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 largest key size: 2280
4th M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 4
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 3.x) slots: 1
2nd M.2 largest key size: 2280
1st M.2 largest key size: 22110
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste.
