Processor
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
Processor manufacturer: AMD
Maximum internal memory supported by processor: 256 GB
Graphics
On-board graphics card: No
Features
Product colour: Black
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870E
PC health monitoring: CPU, Voltage, Fan, Temperature
Motherboard form factor: ATX
Motherboard chipset family: AMD
Memory
Memory slots type: DIMM
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Supported memory clock speeds: 5600 MHz, 4800, 8400
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 8400 MHz
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Wi-Fi standards: 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Ethernet LAN: Yes
LAN controller: Realtek RTL8126
Internal I/O
EPS power connector (8-pin): Yes
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 8
Number of HDDs supported: 4
Rear panel I/O ports
S/PDIF out port: Yes
Microphone in: Yes
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
HDMI version: 2.1
DisplayPort version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB4 Gen 2x2 ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Expansion slots
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
3rd M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 5.0
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
4th M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 2280
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage.
