Processor
Processor manufacturer: Intel
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Graphics
Parallel processing technology support: Not supported
Features
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: Intel Z790
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Memory
Supported memory clock speeds: 5600, 7200, 6400 MHz, 6600, 4800, 6800, 7000, 5800, 5400, 5200, 6000, 6200
Supported memory clock speed (max): 5333 MHz
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Unbuffered memory: Yes
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Weight & dimensions
Depth: 243.8 mm
Width: 304.8 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b
Bluetooth version: 5.3
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Front panel connector: Yes
Front panel audio connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 2.0 connectors: 4
Number of SATA II connectors: 6
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Chassis intrusion connector: Yes
TPM connector: Yes
BIOS
BIOS type: EFI AMI
Packaging content
Cables included: SATA
Storage controllers
RAID levels: 5, 10, 0
Supported storage drive interfaces: M.2, PCI Express
Supported storage drive types: HDD & SSD
Internal storage capacity: 10 GB
Rear panel I/O ports
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
S/PDIF out port: Yes
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
