Processor
Processor manufacturer: Intel
Supported processor sockets: Intel LGA1851
Processor socket: LGA 1851 (Socket V1)
Maximum internal memory supported by processor: 256 GB
Compatible processor series: Intel Core Ultra (Series 2)
Graphics
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Audio chip: Realtek ALC1220P
Windows operating systems supported: Windows 11
Motherboard form factor: ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel Z890
Product colour: Black
Memory
Number of memory slots: 4
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 9200 MHz
Maximum internal memory: 256 GB
Supported memory clock speeds: 9200, 6400
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Ethernet interface type: 5 Gigabit Ethernet
WLAN controller model: Killer Wi-Fi 7 BE1750
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11b, 802.11a, Wi-Fi 6 (802.11ax)
Bluetooth version: 5.4
Ethernet LAN: Yes
Bluetooth: Yes
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 4
CPU fan connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
Total number of SATA connectors: 4
ATX Power connector (24-pin): Yes
Number of EPS power connectors (8-pin): 1
Storage controllers
RAID levels: 10, 5, 0
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 4
Number of HDDs supported: 8
Supported storage drive types: HDD & SSD
RAID support: Yes
Rear panel I/O ports
HDMI version: 2.1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Thunderbolt ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 4
PCI Express x4 (Gen 4.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
