Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
On-board graphics card: No
Features
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870E
Component for: PC
Motherboard form factor: Extended ATX
PC health monitoring: CPU, Temperature, Voltage, Fan
Motherboard chipset family: AMD
Product colour: Black
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Supported memory clock speed (max): 9000 MHz
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory clock speeds: 4800, 5600
Maximum internal memory: 256 GB
Weight & dimensions
Depth: 277 mm
Width: 304.8 mm
Network
Ethernet LAN: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Bluetooth version: 5.4
Ethernet interface type: 5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Internal I/O
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 2
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Number of SATA III connectors: 4
CPU fan connector: Yes
BIOS
System Management BIOS (SMBIOS) version: 3.7
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
ACPI version: 6.5
Storage controllers
Number of storage drives supported: 9
Number of HDDs supported: 4
RAID levels: 0, 1, 10
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI version: 2.1
USB4 Gen 2x2 ports quantity: 2
Microphone in: Yes
S/PDIF out port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 5
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 8
Expansion slots
2nd M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 22110
5th M.2 highest PCI Express generation: 4.0
4th M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 2280
2nd M.2 largest key size: 2280
5th M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 5
PCI Express x16 (Gen 3.x) slots: 1
