Processor
Maximum internal memory supported by processor: 128 GB
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Supported processor sockets: Intel LGA1851
Graphics
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Component for: PC
Motherboard chipset: Intel Z890
Motherboard form factor: ATX
Windows operating systems supported: Windows 11
Motherboard chipset family: Intel
Audio chip: Realtek ALC4080
Product colour: Black
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Memory slots type: DIMM
Supported memory clock speeds: 6400, 4800
Memory channels: Dual-channel
Maximum internal memory: 128 GB
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 9600 MHz
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax)
Bluetooth version: 5.4
Ethernet LAN: Yes
Ethernet interface type: 5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Internal I/O
Total number of SATA connectors: 6
EPS power connector (8-pin): Yes
Number of EPS power connectors (8-pin): 1
Number of SATA III connectors: 6
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
CPU fan connector: Yes
Storage controllers
Number of storage drives supported: 6
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 5, 10
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Thunderbolt ports quantity: 2
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
Expansion slots
PCI Express x1 slots: 1
Number of M.2 (M) slots: 6
PCI Express x16 (Gen 5.x) slots: 3
