Design
Illumination: No
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black
Power
Max output current (-12V): 0.3 A
Max output current (+5V): 22 A
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 22 A
Max output current (+5Vsb): 3 A
Combined power (-12V): 3.6 W
Power Factor Correction (PFC) type: Active
Combined power (+5V): 120 W
Efficiency: 90%
Combined power (+12V): 1000 W
Power protection features: Over power, Short circuit, Over voltage, Under voltage, Over current, Overheating
Combined power (+3.3V): 120 W
Max output current (+12V): 83.5 A
Total power: 1000 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Weight & dimensions
Width: 150 mm
Depth: 150 mm
Height: 86 mm
Performance
Power supply unit (PSU) form factor: ATX
Purpose: PC/Server
Bearing technology: FDB
ATX version: 3.0
80 PLUS certification: 80 PLUS Gold
Ports & interfaces
Peripheral (Molex) power cable length: 1100, 850 mm, 700, 500 mm, 650
SATA power cable length: 650, 700 mm, 500 mm, 850
Number of SATA power connectors: 12
PCI Express power cable length: 75 cm
Motherboard power cable length: 60 cm
PCI Express power connectors (6+2 pin): 6
Cabling type: Fully-Modular
EPS power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (16-pin): 1
Peripheral (Molex) power connectors (4-pin): 4
Floppy disk drive connector: Yes
EPS power connector (8-pin): No
Other features
EPS cable length: 70 cm
