Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
On-board graphics card: No
Features
Motherboard chipset: AMD B850
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Audio chip: Realtek ALC4080
Product colour: White
Windows operating systems supported: Windows 11 x64
Motherboard chipset family: AMD
Memory
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Supported memory clock speed (max): 8400 MHz
ECC сompatibility: Non-ECC
Supported memory clock speeds: 4800, 8400 MHz, 5600
Maximum internal memory: 256 GB
Weight & dimensions
Depth: 243.8 mm
Width: 304.8 mm
Network
Ethernet LAN: Yes
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 6E (802.11ax)
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Bluetooth: Yes
Internal I/O
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
Number of RGB LED pin headers: 3
Number of CPU fan connectors: 6
Number of water pump connectors: 1
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
CPU fan connector: Yes
Number of SATA III connectors: 4
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 8
Supported storage drive types: HDD & SSD
RAID levels: 0, 10, 1
RAID support: Yes
Supported storage drive interfaces: M.2, Micro SATA III
Rear panel I/O ports
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 3
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
4th M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 5.0
1st M.2 highest PCI Express generation: 5.0
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
1st M.2 largest key size: 22110
3rd M.2 largest key size: 2280
4th M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 4
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty.
