Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
PC health monitoring: CPU, Temperature, Voltage, Fan
Product colour: White
Audio chip: Realtek ALC4080
Motherboard form factor: mini ATX
Component for: PC
Motherboard chipset family: AMD
Memory
Supported memory clock speeds: 9000, 7000, 8000
Maximum internal memory: 256 GB
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 9000 MHz
Number of memory slots: 2
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
LAN controller: Realtek RTL8126
Bluetooth: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 6E (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Ethernet interface type: 5 Gigabit Ethernet
Internal I/O
ATX Power connector (24-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
EPS power connector (8-pin): Yes
Number of SATA III connectors: 2
Total number of SATA connectors: 2
CPU fan connector: Yes
BIOS
BIOS type: UEFI AMI
BIOS memory size: 512 Mbit
ACPI version: 6.5
System Management BIOS (SMBIOS) version: 3.7
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 2
Number of storage drives supported: 3
RAID levels: 10, 1, 0, 5
Rear panel I/O ports
S/PDIF out port: Yes
USB4 Gen 2x2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 2
HDMI ports quantity: 1
Expansion slots
1st M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
