Processor
Supported processor sockets: Intel LGA1851
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Features
Windows operating systems supported: Windows 11 x64
Audio chip: Realtek ALC1220P
Product colour: Black
Motherboard chipset family: Intel
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z890
Memory
Number of memory slots: 4
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory clock speed (max): 9200 MHz
Supported memory types: DDR5-SDRAM
Supported memory clock speeds: 9200, 6400, 4800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Wi-Fi standards: 802.11g, 802.11a, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: Killer Wi-Fi BE1750x
Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet
Bluetooth: Yes
Internal I/O
CPU fan connector: Yes
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Total number of SATA connectors: 4
USB 3.2 Gen 2x2 Type-C ports quantity: 1
USB 2.0 connectors: 4
Front panel audio connector: Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 1, 0, 10, 5
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI version: 2.1
Thunderbolt ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 10
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Expansion slots
Number of M.2 (M) slots: 5
PCI Express x16 slots: 3
