Processor
Supported processor sockets: Intel LGA1851
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Features
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset: Intel Z890
Product colour: White
Component for: PC
Audio chip: Realtek ALC1220P
Motherboard chipset family: Intel
Memory
Maximum internal memory: 256 GB
Supported memory clock speeds: 4800, 6400, 9200
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Supported memory clock speed (max): 9200 MHz
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b
Ethernet interface type: 5 Gigabit Ethernet
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: Killer Wi-Fi 7 BE1750
Bluetooth version: 5.4
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Total number of SATA connectors: 4
Number of SATA III connectors: 4
USB 2.0 connectors: 4
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
RAID levels: 5, 10, 0
Number of storage drives supported: 4
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 9
Rear panel I/O ports
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Thunderbolt ports quantity: 2
Expansion slots
PCI Express x1 slots: 1
PCI Express x16 slots: 2
Number of M.2 (M) slots: 5
