Processor
Supported processor sockets: Intel LGA1851
Maximum internal memory supported by processor: 128 GB
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Graphics
On-board graphics card: No
Features
Component for: PC
Motherboard chipset: Intel Z890
Motherboard chipset family: Intel
Product colour: White
Audio output channels: 7.1 channels
Motherboard form factor: mini ITX
Audio chip: Realtek ALC4080
Windows operating systems supported: Windows 11 x64
Memory
ECC сompatibility: Non-ECC
Supported memory clock speeds: 4800, 8600, 6400
Maximum internal memory: 128 GB
Memory channels: Dual-channel
Number of memory slots: 2
Supported memory clock speed (max): 8600 MHz
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b
Ethernet LAN: Yes
Bluetooth version: 5.4
Wi-Fi: Yes
WLAN controller model: Killer Wi-Fi 7 BE1750
Ethernet interface type: 5 Gigabit Ethernet
Internal I/O
Number of SATA III connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Total number of SATA connectors: 2
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID levels: 5, 0, 10
RAID support: Yes
Number of storage drives supported: 2
Number of HDDs supported: 6
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 7
HDMI ports quantity: 1
HDMI version: 2.1
Thunderbolt ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Expansion slots
PCI Express x16 slots: 1
Number of M.2 (M) slots: 4
