Processor
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Graphics
On-board graphics card: No
Parallel processing technology support: Not supported
Features
Product colour: Black
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11, Windows 10
Motherboard chipset: AMD A620A
Component for: PC
Memory
Memory channels: Dual-channel
Supported memory clock speeds: 5600, 7200, 4800 MHz
Number of memory slots: 2
Memory slots type: DIMM
Maximum internal memory: 128 GB
Supported memory types: DDR5-SDRAM
Unbuffered memory: Yes
Supported memory clock speed (max): 7200 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 243.8 mm
Width: 226 mm
Network
Wi-Fi: Yes
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
BIOS
BIOS type: UEFI AMI
ACPI version: 6.5
BIOS memory size: 512 Mbit
System Management BIOS (SMBIOS) version: 3.7
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 1, 10
RAID support: Yes
Number of HDDs supported: 4
Number of storage drives supported: 6
Rear panel I/O ports
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) ports quantity: 1
DisplayPort version: 1.4
HDMI version: 2.1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 3.x) slots: 1
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
