Processor
Supported processor sockets: LGA 1700
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Processor socket: LGA 1700
Graphics
On-board graphics card: No
Features
Motherboard form factor: ATX
Windows operating systems supported: Windows 10, Windows 11
Audio output channels: 7.1 channels
Power source type: ATX
Product colour: Black
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Memory
Supported memory clock speeds: 4600, 3400, 2400, 3200, 2666, 4266, 3466, 3800, 3333, 5333 MHz, 5200, 2133 MHz, 4200, 2933, 3600, 3733, 4400, 5000, 5066, 4000, 4800
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Supported memory clock speed (max): 5333 MHz
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR4-SDRAM
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Bluetooth: Yes
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
Front panel connector: Yes
TPM connector: Yes
CPU fan connector: Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
RAID support: Yes
RAID levels: 10, 0, 1, 5
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots
PCI Express x16 slots: 5
Number of M.2 (M) slots: 2
Safety warning
Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Before starting any maintenance or installation, disconnect the product from the power supply.
