Processor
Compatible processor series: Intel® Pentium® Gold, Intel® Celeron®
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Features
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Motherboard chipset: Intel B760
Motherboard chipset family: Intel
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Power source type: ATX
Memory
ECC сompatibility: Non-ECC
Supported memory clock speeds: 6800, 5200, 5800, 5400, 6400, 4800, 6600, 5000, 6000, 5600, 6200
Maximum internal memory: 192 GB
Unbuffered memory: Yes
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 243.8 mm
Depth: 243.8 mm
Network
LAN controller: Realtek RTL8111H
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
TPM connector: Yes
CPU fan connector: Yes
Chassis intrusion connector: Yes
Parallel connector: Yes
Front panel connector: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
Number of COM connectors: 1
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
BIOS
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: SATA III
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10, 5
Number of storage drives supported: 6
RAID support: Yes
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPorts quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
DisplayPort version: 1.4
USB 2.0 ports quantity: 4
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI version: 1.4
PS/2 ports quantity: 2
Microphone in: Yes
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 2
Safety warning
Warnings: Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage.
