Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Maximum internal memory supported by processor: 256 GB
Graphics
On-board graphics card: No
Features
Product colour: Black
Motherboard form factor: ATX
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Motherboard chipset: AMD B840
Memory
Supported memory clock speeds: 8000, 4800, 5600
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8000 MHz
ECC сompatibility: Non-ECC
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Bluetooth: Yes
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of chassis fan connectors: 5
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
USB 2.0 connectors: 4
Number of RGB LED pin headers: 3
Number of water pump connectors: 1
Number of CPU fan connectors: 1
RGB LED pin header: Yes
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS
BIOS type: UEFI AMI
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, Micro SATA III
RAID levels: 0, 10, 1
Number of HDDs supported: 4
Number of storage drives supported: 6
Rear panel I/O ports
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Expansion slots
PCI Express x16 (Gen 3.x) slots: 4
Number of M.2 (M) slots: 2
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste.
