Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Features
Motherboard chipset: AMD B840
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Power source type: ATX
Memory
Unbuffered memory: Yes
Supported memory clock speeds: 6400, 8000, 5600 MHz, 4800
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 8000 MHz
Weight & dimensions
Width: 243.8 mm
Depth: 243.8 mm
Network
Bluetooth: Yes
Wi-Fi: Yes
Wi-Fi standards: 802.11ac, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11n
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Front panel connector: Yes
Front panel audio connector: Yes
TPM connector: Yes
USB 2.0 connectors: 4
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
CPU fan connector: Yes
Total number of SATA connectors: 4
Number of RGB LED pin headers: 4
RGB LED pin header: Yes
BIOS
Clear CMOS button: Yes
Packaging content
Quick installation guide: Yes
Antenna included: Yes
Storage controllers
RAID levels: 1, 10, 0
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 2.0 ports quantity: 4
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
Expansion slots
PCI Express x16 slots: 1
Number of M.2 (M) slots: 2
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
PCI Express x1 slots: 1
1st M.2 highest PCI Express generation: 4.0
