Processor
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Graphics
On-board graphics card: No
Features
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Component for: PC
Product colour: Black
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 4
Supported memory clock speed (max): 8200 MHz
ECC сompatibility: Non-ECC
Supported memory clock speeds: 8200 MHz, 5600, 4800
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Bluetooth version: 5.4
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Internal I/O
RGB LED pin header: Yes
Number of water pump connectors: 1
Number of CPU fan connectors: 1
Number of SATA III connectors: 4
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Number of RGB LED pin headers: 3
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
CPU fan connector: Yes
Storage controllers
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, Micro SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of storage drives supported: 7
RAID levels: 1, 0
Rear panel I/O ports
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 2
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
Number of M.2 (M) slots: 3
2nd M.2 largest key size: 22110
