Processor
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Maximum number of SMP processors: 1
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i9
Graphics
Parallel processing technology support: Not supported
Features
Audio output channels: 7.1 channels
Motherboard chipset: Intel H610
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Memory
Supported memory clock speed (max): 3200 MHz
Maximum internal memory: 64 GB
Supported memory clock speeds: 3200, 2666, 3000, 2933, 2133
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Weight & dimensions
Height: 65 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
TPM connector: Yes
12V power connector: Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
CPU fan connector: Yes
USB 2.0 connectors: 4
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 1
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging content
Cables included: SATA
Drivers included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
Other features
Weight: 760 g
Safety warning
Warnings: Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply.
