Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Graphics
On-board graphics card: No
Features
Motherboard chipset: AMD X870E
Product colour: Black
Audio output channels: 7.1 channels
PC health monitoring: CPU, Fan, Voltage, Temperature
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 11 x64
Motherboard form factor: ATX
Component for: PC
Motherboard chipset family: AMD
Memory
Supported memory clock speed (max): 8200 MHz
Maximum internal memory: 256 GB
Supported memory clock speeds: 8200, 5600, 4800
ECC сompatibility: Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Network
Bluetooth: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
RGB LED pin header: Yes
USB 2.0 connectors: 6
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
TPM connector: Yes
CPU fan connector: Yes
BIOS
BIOS memory size: 512 Mbit
BIOS type: UEFI AMI
ACPI version: 6.5
System Management BIOS (SMBIOS) version: 3.7
Storage controllers
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
RAID levels: 1, 0
Rear panel I/O ports
USB4 Gen 2x2 ports quantity: 1
USB4 Gen 3x2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
HDMI ports quantity: 1
DisplayPorts quantity: 2
DisplayPort version: 1.4
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 slots: 3
1st M.2 highest PCI Express generation: 5.0
PCI Express x1 slots: 1
3rd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 22110
Number of M.2 (M) slots: 3
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
