Processor
Processor socket: LGA 1700
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Graphics
Parallel processing technology support: Not supported
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: Intel Z790
Motherboard form factor: ATX
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Product colour: Black
Memory
ECC сompatibility: Non-ECC
Supported memory clock speeds: 6400 MHz, 5000, 4800, 6000, 5800, 5400, 6600, 7000, 6800, 5200
Supported memory types: DDR5-SDRAM
Maximum internal memory: 128 GB
Supported memory clock speed (max): 7000 MHz
Number of memory slots: 4
Weight & dimensions
Depth: 243.8 mm
Width: 304.8 mm
Network
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b, 802.11g
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Bluetooth version: 5.3
Internal I/O
Number of SATA III connectors: 6
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Front panel audio connector: Yes
Front panel connector: Yes
USB 2.0 connectors: 4
TPM connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Bundled software: Drivers
MSI Center
Intel Extreme Tuning Utility
CPU-Z MSI GAMING
Norton 360 Deluxe
AIDA64 Extreme - MSI Edition
Packaging content
Cables included: SATA
Storage controllers
RAID support: Yes
RAID levels: 5, 0, 1, 10
Supported storage drive interfaces: M.2, PCI Express
Supported storage drive types: HDD & SSD
Internal storage capacity: 10 GB
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI version: 2.1
DisplayPort version: 1.4
S/PDIF out port: Yes
DisplayPorts quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 4
Safety warning
Warnings: Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Avoid direct contact with electronics to prevent electrostatic damage.
