Processor
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Graphics
On-board graphics card: No
Features
Audio chip: Realtek ALC897
Product colour: Black
Motherboard chipset: Intel Z890
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Motherboard form factor: ATX
Motherboard chipset family: Intel
Memory
Maximum internal memory: 256 GB
Supported memory clock speeds: 9200, 6400
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 9200 MHz
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 5 Gigabit Ethernet
Bluetooth version: 5.4
Wi-Fi: Yes
Internal I/O
Number of EPS power connectors (8-pin): 1
EPS power connector (8-pin): Yes
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
CPU fan connector: Yes
TPM connector: Yes
Total number of SATA connectors: 4
ATX Power connector (24-pin): Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID levels: 10, 5, 0, 1
Number of HDDs supported: 8
Number of storage drives supported: 4
RAID support: Yes
Rear panel I/O ports
DisplayPort version: 1.4
HDMI version: 2.1
Thunderbolt ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Expansion slots
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x4 (Gen 4.x) slots: 2
