Processor
Maximum internal memory supported by processor: 256 GB
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Graphics
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Component for: PC
Motherboard form factor: ATX
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
PC health monitoring: Fan, Temperature, Voltage
Motherboard chipset: Intel Z890
Product colour: Black
Memory
Supported memory clock speed (max): 8600 MHz
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory clock speeds: 4800, 6400, 8600
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Maximum internal memory: 256 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Bluetooth: Yes
Bluetooth version: 5.4
Wi-Fi: Yes
Internal I/O
Number of SATA III connectors: 4
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Storage controllers
RAID support: Yes
RAID levels: 0, 1, 10, 5
Number of storage drives supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 7
Rear panel I/O ports
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI version: 2.1
Thunderbolt ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 slots: 4
