Design Cooling type: Active Illumination: No On/off switch: Yes Product colour: Black Fan diameter: 13.5 cm Number of fans: 1 fan(s) Fan speed: 500 - 1800 RPM
Power Power Factor Correction (PFC) type: Active Power protection features: Under voltage, Over current, Overheating, Short circuit, Over voltage, Over power Combined power (+3.3V): 120 W Efficiency: 90% Total power: 1000 W Combined power (+12V): 999.6 W AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Combined power (+5V): 120 W Max output current (+3.3V): 22 A Max output current (+12V): 83.3 A Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A Combined power (-12V): 3.6 W Combined power (+5Vsb): 15 W Max output current (+5V): 22 A Number of +12V rail(s): 1
Weight & dimensions Depth: 150 mm Height: 86 mm Width: 150 mm
Performance Power supply unit (PSU) form factor: ATX ATX version: 3.1 Purpose: PC Bearing technology: FDB 80 PLUS certification: 80 PLUS Gold
Ports & interfaces EPS power connector (8-pin): No Cabling type: Fully-Modular Peripheral (Molex) power connectors (4-pin): 1 PCI Express power connectors (6+2 pin): 4 Motherboard power connector: 24-pin ATX Peripheral (Molex) power cable length: 500, 450 mm EPS power connector (4+4 pin): Yes Number of SATA power connectors: 12 SATA power cable length: 500, 150 Motherboard power cable length: 60 cm PCI Express power connectors (16-pin): 1
Other features Fan's mean time to failure (MTTF): 150000 h
