Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Features
Motherboard chipset family: AMD
Motherboard form factor: ATX
Motherboard chipset: AMD X870E
Memory
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Number of memory slots: 4
ECC сompatibility: Non-ECC
Maximum internal memory: 256 GB
Weight & dimensions
Width: 304.8 mm
Depth: 243.8 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, 802.11g
Bluetooth version: 5.4
Wi-Fi: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
Number of SATA III connectors: 4
TPM connector: Yes
Number of chassis fan connectors: 6
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
CPU fan connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Number of CPU fan connectors: 1
USB 2.0 connectors: 6
Storage controllers
RAID levels: 10, 1, 5, 0
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI version: 2.1
Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports : 1
USB4 Gen 3x2 ports quantity: 1
Expansion slots
PCI Express x16 (Gen 3.x) slots: 3
PCI Express x1 slots: 1
