Processor
Supported processor sockets: Intel LGA1851
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Processor socket: LGA 1851 (Socket V1)
Features
Motherboard chipset family: Intel
Product colour: Black
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 11
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z890
Motherboard form factor: ATX
Memory
Supported memory clock speed (max): 8800 MHz
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory clock speeds: 8800, 6400, 4800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi standards: 802.11g, IEEE 802.11n, IEEE 802.11ax, 802.11a, 802.11b, IEEE 802.11ac, Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Wi-Fi: Yes
Internal I/O
Number of EPS power connectors (8-pin): 1
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
Total number of SATA connectors: 4
Storage controllers
RAID support: Yes
RAID levels: 0, 5, 10, 1
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
Thunderbolt ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 slots: 4
