Certification: CE EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014CE-LVD: EN 62368-1:2014EN 55032:2015, Class A, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55024:2010+A1:2015;EN 55035:2017, EN 50130-4:2011+A1:2014, CE LVD: EN 62368-1:2014, FCC: 47 CFR FCC Part15, SubpartB, Class A 2023-02-15
Features
Product colour: Black
Power
Power consumption (typical): 10 W
Power source type: DC
DC output voltage: 12
Current: 2 A
Operational conditions
Storage relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Package weight: 1.41 kg
Height: 47.6 mm
Weight: 810 g
Width: 260 mm
Depth: 232.7 mm
Supported resolutions: 4608x3472, 3840x2160, 1920x1080, 1280x1024, 1280x720, 1920x1080, 1280x1024, 1280x720
Performance
Video formats supported: H.265, H.264, H.265+, H.264+
Maximum resolution: 4608 x 3472 pixels
Total megapixels: 16 MP
Playback modes: Instant playback, general playback, event playback, smart playback
Backup function: Yes
Video motion detection: Yes
Audio codecs: G.711a, G.711Mu, G.726, PCM
Video input channels: 4 channels
Recording modes: Motion detection, manual recording, smart recording, alarm
People counting function: No
Storage
HDD interface: SATA III
Maximum storage capacity: 16 TB
Ports & interfaces
Power over Ethernet (PoE): No
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
Number of SATA connectors: 1
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
Ethernet LAN data rates: 10,100 Mbit/s
RCA input: 1
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
