Processor
Built-in processor: Yes
Certification: CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Features
Rack mounting: Yes
Rack capacity: 1U
Product colour: Black
Power
Power consumption (typical): 10 W
Output current: 2 A
Output voltage: 12 V
Operational conditions
Operating relative humidity (H-H): 10 - 93%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Height: 47.6 mm
Package weight: 1.38 kg
Package height: 314 mm
Weight: 810 g
Width: 260 mm
Package depth: 89 mm
Depth: 232.5 mm
Package width: 334 mm
System requirements
Browser supported: Chrome; IE; Safari; Edge; Firefox
Mobile operating systems supported: Android, iOS
Supported resolutions: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Performance
Video motion detection: Yes
Video formats supported: H.264+, H.264, H.265+, H.265
Audio formats supported: G.711 A-law, G.726, PCM, G.711 μ-law
Input bandwidth: 80 Mbit/s
Video recording modes: 1080p, 720p, 960p
Image formats supported: MJPEG
Face detection: Yes
Video input channels: 16 channels
Output bandwidth: 60 Mbit/s
Operating system installed: Embedded LINUX
Maximum resolution: 3840 x 2160 pixels
Wireless LAN features
Wi-Fi: No
Ports & interfaces
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
Audio RCA inputs: 1
Ethernet LAN (RJ-45) ports: 1
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
eSATA ports quantity: 1
Ethernet LAN data rates: 100, 10
Hard drive
Maximum storage capacity: 20 TB
HDD interface: SATA
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
