Certification: CE EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014; CE LVD: EN 62368-1:2014; FCC: 47 CFR FCC Part15, SubpartB, Class A 2023-06-15
Features
Product colour: Black
Power
Power consumption (typical): 10 W
DC output voltage: 12
Power source type: DC
Current: 4 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Storage relative humidity (H-H): 10 - 93%
Weight & dimensions
Depth: 284.2 mm
Height: 53 mm
Width: 375 mm
Weight: 1.51 kg
Performance
People counting function: Yes
Output bandwidth: 180 / 256 Mbit/s
Maximum resolution: 4608 x 3472 pixels
Total megapixels: 16 MP
Backup function: Yes
Video formats supported: H.265+, M-JPEG, H.265, H.264+, H.264
Video input channels: 16 channels
Input bandwidth: 180 / 256 Mbit/s
Audio
Audio codecs: G.711a, G.711Mu, G.726, PCM
Storage
Maximum storage capacity: 2 x 16 TB
HDD interface: SATA
Ports & interfaces
Number of SATA connectors: 2
Alarm input channels: 4
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
Alarm output channels: 2
Ethernet LAN data rates: 10,100,1000 Mbit/s
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
Power over Ethernet (PoE): No
Ethernet LAN (RJ-45) ports: 1
RCA input: 1
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
