Design Product colour: Red, Beige Number of fans: 1 fan(s) Number of fan blades: 9 Fan connector: 4-pin
Power Maximum current: 0.14 A Voltage: 12 V Power supply: 1.68 W
Weight & dimensions Package width: 150 mm Package weight: 355 g Package depth: 34 mm Package height: 210 mm Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance Airflow: 102.1 m³/h Pulse-width modulation (PWM) support: Yes Rotational speed (min): 450 RPM Rotational speed (max): 2000 RPM Bearing type: Self-Stabilising Oil-pressure Bearing (SSO) Fan diameter: 12 cm Type: Fan Suitable for: Computer case Compatible processor series: Not supported Supported processor sockets: Not supported Noise level (high speed): 22.6 dB Airflow with LNA (max): 84.5 m³/h Rotational speed with LNA (max): 1700 RPM Noise level with LNA (max): 18.8 dB Maximum air pressure: 2.34 mmH2O
Other features Mean time to failure (MTTF): 150000 h
Logistics data Products per master (outer) case: 36 pc(s) Master (outer) case gross weight: 14.4 kg Master (outer) case length: 380 mm Master (outer) case height: 380 mm Master (outer) case width: 375 mm
