Technical details
Warranty period: 6 year(s)
Design
Number of fans: 2 fan(s)
Material: Copper, Aluminium
Fan connector: 4-pin
Power
Voltage: 12 V
Weight & dimensions
Weight: 1.52 kg
Height: 168 mm
Depth: 152 mm
Width: 150 mm
Performance
Supported processor sockets: LGA 1200 (Socket H5), Socket AM4, LGA 1156 (Socket H), LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1851, Socket AM5, LGA 1700
Type: Air cooler
Fan diameter: 14 cm
Bearing type: Self-Stabilising Oil-pressure (SSO) bearing
Rotational speed (min): 1250 RPM
Suitable location: Processor
Pulse-width modulation (PWM) support: Yes
Noise level (high speed): 24.8 dB
Airflow: 155.6 m³/h
Noise level (low speed): 19.7 dB
Rotational speed (max): 1500 RPM
Other features
Mean time to failure (MTTF): 150000 h
Safety warning
Warnings: Ensure that the unit is switched off before starting to assemble or dismantle the cooling unit., Take appropriate precautions during installation to avoid damage to computer components., Do not touch the fan during operation.
