Design
Radiator material: Aluminum
Product colour: Black
Fan connector: 4-pin
Number of heat pipes: 6
Base plate material: Copper
Material: Aluminium, Cooper
Number of fans: 1 fan(s)
Power
Power consumption (typical): 1.56 W
Voltage: 12 V
Weight & dimensions
Height: 160 mm
Width: 150 mm
Weight: 1.15 kg
Depth: 135 mm
Performance
Supported processor sockets: LGA 2011 (Socket R), Socket AM3+, Socket FM2+, LGA 1150 (Socket H3), Socket FM1, LGA 2066, LGA 1200 (Socket H5), Socket FM2, Socket AM2, LGA 1151 (Socket H4), LGA 2011-v3 (Socket R), Socket AM2+, LGA 1156 (Socket H), LGA 1155 (Socket H2), Socket AM3
Pulse-width modulation (PWM) support: Yes
Rotational speed (min): 300 RPM
Type: Cooler
Rotational speed (max): 1500 RPM
Quantity per pack: 1 pc(s)
Mean time between failures (MTBF): 150000 h
Airflow: 140.2 m³/h
Noise level (high speed): 24.6 dB
Suitable location: Processor
Fan diameter: 14 cm
Bearing type: Self-Stabilising Oil-pressure Bearing (SSO)
Packaging content
Package type: Box
Mounting kit: Yes
Screws included: Yes
Logistics data
Harmonized System (HS) code: 84733080
