Design
Product colour: Metallic, Copper
Material: Copper, Aluminium
Power
Power consumption (typical): 1.56 W
Thermal Design Power (TDP): 220 W
Voltage: 12 V
Weight & dimensions
Package height: 235 mm
Package weight: 1.98 kg
Weight: 1.15 kg
Width: 150 mm
Package width: 190 mm
Package depth: 225 mm
Depth: 190 mm
Height: 165 mm
Performance
Supported processor sockets: Socket AM3+, Socket FM2+, LGA 2011-v3 (Socket R), Socket AM2+, Socket AM3, Socket AM2, Socket FM2, Socket FM1
Compatible processor series: Intel® Core™ i7, Intel® Core™ i3, Intel® Core™ i5
Type: Cooler
Maximum air pressure: 2.08 mmH2O
Noise level (high speed): 24.6 dB
Mean time between failures (MTBF): 150000 h
Airflow: 140.2 m³/h
Rotational speed (max): 1500 RPM
Rotational speed (min): 300 RPM
Suitable location: Processor
Fan diameter: 14 cm
Logistics data
Harmonized System (HS) code: 84733080
