Technical details
Sustainability compliance: Yes
Design
Number of fans: 1 fan(s)
Cooling type: Active
Fan diameter: 12 cm
Fan speed: 2400 - 2400 RPM
Product colour: Black
On/off switch: Yes
Power
Max output current (+5Vsb): 2.5 A
Combined power (-12V): 3.6 W
Combined power (+12V): 750 W
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current
Combined power (+5V): 120 W
Maximum input current (@220V): 5 A
Max output current (+3.3V): 20 A
Max output current (+12V): 62.5 A
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 120 W
Maximum input current (@110V): 10 A
AC input frequency: 50/60 Hz
Total power: 750 W
Max output current (-12V): 0.3 A
AC input voltage: 100 - 240 V
Combined power (+5Vsb): 12.5 W
Input current: 10-5 A
Max output current (+5V): 20 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm
Performance
Purpose: PC
ATX version: 2.53
Noise level: 39.92 dB
EPS version: 2.92
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Certificates
Compliance certificates: UKCA, REACH, RoHS, CE, China RoHS
Ports & interfaces
SATA power cable length: 500, 150
Number of SATA power connectors: 4
PCI Express power connectors (6+2 pin): 2
Motherboard power connector: 24-pin ATX
Motherboard power cable length: 60 cm
Peripheral (Molex) power cable length: 500, 150
Peripheral (Molex) power connectors (4-pin): 4
ATX Power connector (24-pin): Yes
CPU power connector (4+4 pin): Yes
Cabling type: Non-Modular
Logistics data
Warranty period: 5 year(s)
