Design
Fan connector: 4-pin
Material: Rubber, Plastic
Radiator material: Aluminum
Product colour: Black
Base plate material: Copper
Display type: TFT
Number of fans: 2 fan(s)
Power
Fan voltage: 12 V
Pump current: 300 mA
Fan current: 0.3 A
Pump voltage: 12 V
Fan power consumption: 2.76 W
Weight & dimensions
Fan dimensions (W x D x H): 140 x 140 x 25 mm
Cable length: 600 m
Radiator height: 2.7 cm
Tube length: 40 cm
Radiator width: 32.1 cm
Radiator depth: 14 cm
Performance
Pulse-width modulation (PWM) support: Yes
Fan's mean time to failure (MTTF): 60000 h
Pump motor speed (max): 2800 RPM
Suitable location: Processor
Type: All-in-one liquid cooler
Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 3000 Series, Intel® Core™ i7, Intel® Core™ i9, AMD Ryzen 7000 Series, Intel® Core™ i3, AMD Ryzen 9000 Series, Intel® Pentium®, Intel® Core™ i5, Intel® Celeron®
Fan speed (max): 1700 RPM
Noise level (high speed): 30 dB
Bearing type: Fluid Dynamic Bearing (FDB)
Fan speed (min): 500 RPM
Supported processor sockets: LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1156 (Socket H), LGA 1700, LGA 1851, Socket AM4, LGA 1151 (Socket H4), LGA 1150 (Socket H3), Socket AM5
Fan static pressure: 4.45 mmH2O
Maximum airflow: 93.2 cfm
Pump motor speed (min): 1200 RPM
Fan diameter: 14 cm
