Purpose: Off-grid power systems based on energy from PV panels, grid and battery Power supply type: -
Features Power protection features: Overload International Protection (IP) code: IP21 Power current type: AC/AC Product colour: White MPPT function: Yes
Design Display included: Yes Door cooling fan: Yes Control display unit: Yes Recharge indicator: Yes
Power Charging voltage: 54 V Nominal input voltage: 230 V Input frequency: 50/60 Hz Waveform: Sine Output power capacity: 10000 VA AC input voltage: 90 - 280 V Maximum charging current from solar panels (MPPT): 80 A DC battery voltage: 48 V Continuous power: 5000 VA MPPT voltage range: 120 - 450 V Output voltage (VAC): 230 VAC
Weight & dimensions Height: 400 mm Weight: 10 kg Width: 300 mm Depth: 115 mm
Performance Operating temperature (T-T): -10 - 50 °C Operating relative humidity (H-H): 5 - 95% Cooling type: Active Efficiency: 93% Typical switching time: 15 ms
Packaging content Cables included: AC Control display unit: Yes DFU / User manual: Yes
