Design
Cooling type: Active
On/off switch: Yes
Product colour: Black
Number of fans: 1 fan(s)
Power
Power protection features: Over current, Over power, Short circuit, Overcharge, Overheating
Max output current (+12V): 70 A
Combined power (+3.3V): 100 W
Combined power (+5V): 100 W
Max output current (-12V): 0.3 A
Combined power (-12V): 3.6 W
Max output current (+3.3V): 20 A
Total power: 850 W
Max output current (+5Vsb): 2.5 A
AC input voltage: 100 - 240 V
Max output current (+5V): 20 A
Combined power (+5Vsb): 12.5 W
Combined power (+12V): 840 W
Weight & dimensions
Height: 86 mm
Width: 140 mm
Depth: 150 mm
Performance
Purpose: PC
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Gold
Packaging data
Package type: Box
Ports & interfaces
PCI Express connector: Yes
PCI Express power connectors (8-pin): 6
Cabling type: Fully-Modular
Number of SATA power connectors: 4
Peripheral (Molex) power connectors (4-pin): 4
Motherboard power connector: 18+10 pin ATX
Safety warning
Warnings: Do not open the case - risk of electric shock., Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
Hazard pictogram(s): GHS09: Environmental hazard, GHS02: Flammable, GHS07: Harmful
