Design Cooling type: Active Product colour: Black, White On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s)
Power AC input voltage: 200 - 240 V Max output current (+5V): 20 A Maximum input current (@220V): 10 A Input current: 10 A Combined power (+5Vsb): 12.5 W Combined power (-12V): 3.6 W Combined power (+3.3V): 100 W Max output current (+12V): 62 A Combined power (+5V): 100 W AC input frequency: 50/60 Hz Max output current (+3.3V): 20 A Power protection features: Short circuit, Over current, Overcharge, Overheating, Over power Total power: 750 W Max output current (+5Vsb): 2.5 A Combined power (+12V): 744 W Max output current (-12V): 0.3 A
Weight & dimensions Depth: 150 mm Weight: 1.4 kg Width: 140 mm Height: 86 mm
Performance Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX Purpose: PC
Packaging data Package type: Box Package weight: 3.2 kg
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 4 Cabling type: Fully-Modular Number of SATA power connectors: 4 CPU power connector (4+4 pin): Yes Motherboard power connector: 18+10 pin ATX
