Design On/off switch: Yes Product colour: White Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s)
Power AC input frequency: 50/60 Hz Combined power (+12V): 744 W Combined power (-12V): 3.6 W Power protection features: Over power, Overcharge, Short circuit, Over current, Overheating Max output current (+3.3V): 20 A Maximum input current (@220V): 10 A Combined power (+5V): 100 W Max output current (+5Vsb): 2.5 A Input current: 10 A Combined power (+5Vsb): 12.5 W Combined power (+3.3V): 100 W Max output current (+12V): 62 A AC input voltage: 200 - 240 V Total power: 750 W Max output current (+5V): 20 A Max output current (-12V): 0.3 A
Weight & dimensions Weight: 1.4 kg Depth: 150 mm Width: 140 mm Height: 86 mm
Performance Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Purpose: PC
Packaging data Package weight: 3.2 kg Package type: Box
Ports & interfaces CPU power connector (4+4 pin): Yes Number of SATA power connectors: 4 Cabling type: Fully-Modular Motherboard power connector: 18+10 pin ATX Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 4
