Design Product colour: Black On/off switch: Yes Cooling type: Active Fan diameter: 13.5 cm Number of fans: 1 fan(s)
Power Max output current (+12V): 83 A Combined power (+3.3V): 125 W Max output current (-12V): 0.3 A Power protection features: Overcharge, Over power, Over current, Overheating, Short circuit Total power: 1000 W Maximum input current (@110V): 13 A Max output current (+5Vsb): 3 A AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Combined power (+5Vsb): 15 W Input current: 10 - 5 A Max output current (+5V): 25 A Combined power (-12V): 3.6 W Combined power (+5V): 125 W Max output current (+3.3V): 25 A Combined power (+12V): 996 W Maximum input current (@220V): 6.5 A
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Weight: 2.05 kg Depth: 150 mm Height: 86 mm Width: 160 mm
Performance Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Platinum Mean time between failures (MTBF): 100000 h Purpose: PC
Packaging data Package type: Box Package weight: 2.5 kg
Ports & interfaces Cabling type: Fully-Modular PCI Express power connectors (6-pin): 8 Number of SATA power connectors: 4 Peripheral (Molex) power connectors (4-pin): 5 ATX Power connector (24-pin): Yes PCI Express connector: Yes
