Design Product colour: Black Cooling type: Active Fan diameter: 13.5 cm Number of fans: 1 fan(s) On/off switch: Yes
Power AC input frequency: 50/60 Hz Input current: 10 - 5 A AC input voltage: 100 - 240 V Combined power (-12V): 3.6 W Combined power (+12V): 1200 W Combined power (+5V): 125 W Max output current (+3.3V): 25 A Power protection features: Short circuit, Over power, Overheating, Over current, Overcharge Combined power (+3.3V): 125 W Total power: 1200 W Combined power (+5Vsb): 15 W Maximum input current (@110V): 15 A Maximum input current (@220V): 7.5 A Max output current (+5V): 25 A Max output current (+12V): 100 A Max output current (+5Vsb): 3 A Max output current (-12V): 0.3 A
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Width: 160 mm Height: 86 mm Depth: 150 mm
Performance 80 PLUS certification: 80 PLUS Platinum Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX Purpose: PC
