Design
Placement supported: Indoor
Screen shape: Flat
Bezel width (top): 1.19 cm
Orientation: Horizontal/Vertical
Panel mounting interface: 200 x 200 mm, 100 x 100 mm
Bezel width (bottom): 1.19 cm
VESA mounting: Yes
Bezel width (side): 1.19 cm
Product colour: Black
Product design: Digital signage flat panel
Power
Energy efficiency class (SDR): G
Power consumption (standby): 0.5 W
AC input frequency: 50/60 Hz
Power consumption (typical): 26 W
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Display height: 425.4 mm
Display depth: 65.1 mm
Display weight: 5.7 kg
Display width: 726.5 mm
Network
Ethernet LAN: Yes
Performance
On Screen Display (OSD): Yes
Mean time between failures (MTBF): 50000 h
Packaging content
Remote control included: Yes
Cables included: RS-232, Power
Batteries included: Yes
Display
Panel type: ADS
Native refresh rate: 60 Hz
Contrast ratio (typical): 1200:1
Haze rate: 25%
Display diagonal (metric): 80 cm
Display brightness: 400 cd/m²
Display resolution: 1920 x 1080 pixels
Viewing angle, horizontal: 178°
HD type: Full HD
Response time: 8 ms
Viewing angle, vertical: 178°
Display number of colours: 16.7 million colours
Pixel pitch: 0.36375 x 0.36375 mm
Display diagonal: 80 cm (31.5")
Native aspect ratio: 16:9
Contrast ratio (dynamic): 500000:1
Audio
RMS rated power: 10 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
RS-232C: Yes
Card reader integrated: Yes
Audio (L/R) in: 1
USB ports quantity: 4
DVI-I ports quantity: 1
HDMI version: 2.0
DVI port: Yes
USB port: Yes
HDMI ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Audio (L/R) out: 1
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
Compatible memory cards: MicroSD (TransFlash)
Computer system
Audio formats supported: MPEG, HE-AAC, AAC
Video formats supported: H.265, H.264, H.263, MPEG4, VP9, MPEG1, MPEG2
Image formats supported: BMP, PNG, WEBP, JPEG
Computer system: Yes
Internal storage capacity: 16 GB
Internal memory: 3 GB
Built-in processor: Yes
Operating system installed: Android 10
Processor manufacturer: ARM
On-board graphics card model: ARM Mali-G52
Processor family: ARM Cortex
Processor model: A55
