Design
VESA mounting: Yes
Screen shape: Flat
Panel mounting interface: 200 x 200 mm
Product design: Digital signage flat panel
Product colour: Black
Orientation: Horizontal/Vertical
Bezel width (bottom): 1.39 cm
Bezel width (top): 1.39 cm
Bezel width (side): 1.39 cm
Placement supported: Indoor
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (standby): 0.5 W
Energy efficiency class (SDR): G
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Display height: 561.2 mm
Display depth: 63.5 mm
Display weight: 11.1 kg
Display width: 973 mm
Network
Ethernet LAN: Yes
Performance
On Screen Display (OSD): Yes
Mean time between failures (MTBF): 50000 h
Packaging content
Cables included: RS-232, Power
Batteries included: Yes
Remote control included: Yes
Display
Response time: 8 ms
Pixel pitch: 0.2451 x 0.2451 mm
Display resolution: 3840 x 2160 pixels
Viewing angle, vertical: 178°
Display number of colours: 1.07 billion colours
Viewing angle, horizontal: 178°
Display diagonal: 109.2 cm (43")
Contrast ratio (dynamic): 500000:1
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Panel type: ADS
Display diagonal (metric): 108 cm
Contrast ratio (typical): 1200:1
Display brightness: 500 cd/m²
Haze rate: 25%
Native refresh rate: 60 Hz
Audio
Number of built-in speakers: 2
RMS rated power: 10 W
Built-in speaker(s): Yes
Ports & interfaces
DVI-I ports quantity: 1
HDMI version: 2.0
HDMI ports quantity: 2
DVI port: Yes
Ethernet LAN (RJ-45) ports: 1
USB port: Yes
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
RS-232C: Yes
USB ports quantity: 5
Audio (L/R) in: 1
Audio (L/R) out: 1
Computer system
Built-in processor: Yes
Video formats supported: MPEG1, H.265, H.264, H.263, MPEG2, MPEG4, VP9
Processor family: ARM Cortex
On-board graphics card model: ARM Mali-G52
Operating system installed: Android 10
Processor model: A55
Internal memory: 3 GB
Audio formats supported: MPEG, HE-AAC, AAC
Processor manufacturer: ARM
Internal storage capacity: 16 GB
Image formats supported: JPEG, BMP, PNG, WEBP
Computer system: Yes
