Design
Panel mounting interface: 400 x 400
VESA mounting: Yes
Screen shape: Flat
Product colour: Black
Product design: Digital signage flat panel
Bezel width (bottom): 1.49 cm
Placement supported: Indoor
Orientation: Horizontal/Vertical
Bezel width (top): 1.49 cm
Bezel width (side): 1.49 cm
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 47 W
Power consumption (standby): 0.5 W
Energy efficiency class (SDR): E
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Display weight: 14.3 kg
Display depth: 63.5 mm
Display width: 1128.4 mm
Display height: 649 mm
Network
Ethernet LAN: Yes
Performance
On Screen Display (OSD): Yes
Mean time between failures (MTBF): 50000 h
Packaging content
Batteries included: Yes
Cables included: RS-232, Power
Remote control included: Yes
Display
Viewing angle, horizontal: 178°
Display resolution: 3840 x 2160 pixels
Display number of colours: 1.07 billion colours
Viewing angle, vertical: 178°
Display diagonal: 127 cm (50")
Pixel pitch: 0.2854 x 0.2854 mm
HD type: 4K Ultra HD
Response time: 8 ms
Contrast ratio (dynamic): 500000:1
Native aspect ratio: 16:9
Display brightness: 500 cd/m²
Display diagonal (metric): 125.7 cm
Panel type: VA
Haze rate: 25%
Contrast ratio (typical): 4000:1
Native refresh rate: 60 Hz
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 10 W
Ports & interfaces
DVI port: Yes
Ethernet LAN (RJ-45) ports: 1
USB port: Yes
HDMI version: 2.0
HDMI ports quantity: 2
Compatible memory cards: MicroSD (TransFlash)
DVI-I ports quantity: 1
Card reader integrated: Yes
RS-232C: Yes
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity: 5
Audio (L/R) in: 1
Audio (L/R) out: 1
Computer system
Operating system installed: Android 10
Processor model: A55
Video formats supported: H.264, MPEG4, VP9, H.265, MPEG2, H.263, MPEG1
On-board graphics card model: ARM Mali-G52
Built-in processor: Yes
Audio formats supported: HE-AAC, MPEG, AAC
Processor family: ARM Cortex
Internal memory: 3 GB
Processor manufacturer: ARM
Image formats supported: PNG, BMP, JPEG, WEBP
Computer system: Yes
Internal storage capacity: 16 GB
