Technical details
Compliance certificates: RoHS, CE, CB
Design
Bezel width (top): 1.19 cm
Bezel width (bottom): 1.72 cm
Bezel width (side): 1.19 cm
Panel mounting interface: 200 x 200, 100 x 100 mm
VESA mounting: Yes
Power
AC input voltage: 100 - 240 V
Energy efficiency class (SDR): F
AC input frequency: 50/60 Hz
Power consumption (typical): 33 W
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Display height: 245.4 mm
Display width: 726.5 mm
Display depth: 65.1 mm
Display weight: 5.7 kg
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
Mean time between failures (MTBF): 50000 h
Number of OSD languages: 18
On Screen Display (OSD) languages: Russian, Polish, Japanese, Arabic, Portuguese, German, Italian, Dutch, Swedish, Spanish, Finnish, English, Norwegian, Traditional Chinese, French, Turkish, Danish, Simplified Chinese
On Screen Display (OSD): Yes
Packaging content
Cables included: IR sensor, AC, RS-232
Display
Response time: 8 ms
Contrast ratio (dynamic): 500000:1
Viewing angle, horizontal: 178°
Display brightness: 500 cd/m²
HD type: Full HD
Viewing angle, vertical: 178°
Native aspect ratio: 16:9
Display resolution: 1920 x 1080 pixels
Haze rate: 25%
Display diagonal: 81.3 cm (32")
Display number of colours: 16.7 million colours
Pixel pitch: 0.36375 x 0.36375 mm
Panel type: ADS
Contrast ratio (typical): 1200:1
Display technology: LCD
Display diagonal (metric): 80.01 cm
Audio
Number of built-in speakers: 2
RMS rated power: 20 W
Built-in speaker(s): Yes
Ports & interfaces
USB ports quantity: 1
DisplayPorts quantity: 1
USB connector type: USB Type-C, Micro-USB B
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
RS-232 interface: Yes
Remote (IR) input: 1
Remote (IR) output: 1
HDMI version: 2.0
HDMI ports quantity: 2
USB version: 2.0/3.2 Gen 2 (3.1 Gen 2)
Number of antenna connectors: 1
RS-232C: Yes
USB port: Yes
Computer system
Computer system: Yes
Computer system type: System on Chip (SoC)
On-board graphics card model: Mali-G52 MC3
Internal storage capacity: 32 GB
Video formats supported: AVI, WEBM, H.264, VP8, MPEG, MP4, H.263, H.265, MPEG4
Processor cores: 8
Built-in processor: Yes
Operating system version: 14
Audio formats supported: AAC, HEAAC / MPEG
Internal memory: 4 GB
Processor manufacturer: ARM
Image formats supported: JPEG, PNG, BMP
Processor model: A53
Operating system installed: Android
